Camera |
Image Sensor: |
1/3" Progressive Scan CMOS |
Min. Illumination: |
Color: 0.01lux @(F1.2, AGC ON)
B/W: 0.001lux @(F1.2, AGC ON)
0 lux with IR |
Shutter time: |
1/25s to 1/100,000s |
Lens: |
1.6mm, F1.6
Angle of view: 186°(horizontal), 106°(vertical) |
Lens Mount: |
M12 |
Day& Night: |
Electronic |
Digital noise reduction: |
3D DNR |
|
Compression Standard |
Video Compression: |
H.264/M-JPEG |
Bit Rate: |
32 Kbps~8Mbps |
|
Image |
Frame Rate: |
50Hz: 12.5fps (2560 x 1440), 25fps(1920×1080, 1280×720)
60Hz: 15fps (2560 x 1440), 30fps(1920×1080, 1280×720) |
|
Network |
Network Storage: |
NAS |
Protocols: |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, |
Security: |
User Authentication, Watermark, IP address filtering, anonymous access |
|
Interface |
Communication Interface: |
1 RJ45 10M / 100M ethernet interface and 1 RS-485 interface |
On-board storage: |
Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
|
General |
Power Supply: |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption: |
Max. 5.55W |
IR Range: |
15 meters |
Dimensions: |
Φ119.9 x 41.2 |
Weight: |
600g |
|
