Camera |
Image Sensor: |
1/3" Progressive Scan CMOS |
Signal System: |
PAL/NTSC |
Min. Illumination: |
0.07 Lux @(F1.2,AGC ON), 0 Lux with IR |
Shutter time: |
1/3 s to 1/100,000 s |
Lens: |
4mm, 6mm, 16mm optional
Angle of view: 67°(4mm), 43°(6mm), 16.2°(16mm) |
Lens Mount: |
M12 |
Day& Night: |
IR cut filter with auto switch |
Wide Dynamic Range: |
Digital WDR |
Digital noise reduction: |
3D DNR |
|
Compression Standard |
Video Compression: |
H.264/M-JPEG |
Bit Rate: |
32 Kbps – 12 Mbps |
Dual Stream: |
Yes |
|
Image |
Max. Image Resolution: |
2048×1536 |
Frame Rate: |
50Hz: 20fps @2048 × 1536, 25fps @(1920 × 1080, 1280 × 720)
60Hz: 20fps @2048 × 1536, 30fps@(1920 × 1080, 1280 × 720) |
Image Settings: |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
BLC: |
Yes, zone configurable |
ROI: |
Support |
|
Network |
Network Storage: |
NAS |
Alarm Trigger: |
Motion detection, Dynamic Analysis, Tampering alarm |
Protocols: |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
Security: |
User authentication, watermark |
System Compatibility: |
ONVIF, PSIA, CGI, ISAPI |
|
Interface |
Communication Interface: |
1 RJ45 10M / 100M ethernet interface |
|
General |
Operating Conditions: |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
Power Supply: |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption: |
I3: Max. 6W
I5: Max. 7.5W
I8: Max. 10.5W |
Weather Proof: |
IP66 |
IR Range: |
I3: 30 meters
I5: 50 meters
I8: 80 meters |
Dimensions: |
299.71 × 86.48 × 85.11(11.8’’ × 3.4’’ × 3.35’’) |
Weight: |
1200g |
|
